CNLINKO LP12 Plastic Male and Female Industrial Waterproof Pin M12 Connector

Name: CNLINKO LP12 Plastic Male and Female Industrial Waterproof Pin M12 Connector
Brand: CNLINKO
Price: 1 USD

China CNLINKO LP12 Plastic Male and Female Industrial Waterproof Pin M12 Connector wholesale

Place of Origin : Guangdong, China

Brand Name : CNLINKO

Model Number : LP-12 semimetal

MOQ : 10

Type : Power

Application : Industrial, Power

Gender : Male and Female

Housing Material : PBT

Product name : LP-12

Material : PBT Plastic

Current rating : 5A

Wire Gauge : 22-20AWG

Protection Level : IP65/IP67/IP68

Contact Diameter/Number of Contact : 1.0x5

Operating Voltage : 250V

Temperature Rating : -40℃-80℃

Contact Now

Product Description

- Multi-style inner core design (2-8 cores), in line with various industrial requirements, the signal and power supply are

compatible at the same time.

- Spring-pressed design, tightly docked, safe and secure.

- The orientation is strong, and blind insertion can be realized, and the humanized design in the true sense.

-3 core lock screws and solderable optional connection, fully compatible with outdoor installation work.

- Gold-plated contacts, high corrosion resistance and electrical conductivity, effectively coping with changes in temperature rise

caused by current.

- Thermoplastic high temperature resistant plastic case, stable electrical performance, high strength, high temperature resistance

and corrosion resistance.

- Unique docking design, solid extension of infinite line length.

-Flange 4 hole mounting, stable and impeccable, threaded single hole housing installation, suitable for circular opening

industrial installation.

- The product complies with IP68 protection in the assembled state.

Details Images

CNLINKO LP12 Plastic Male and Female Industrial Waterproof Pin M12 Connector

CNLINKO LP12 Plastic Male and Female Industrial Waterproof Pin M12 Connector Images
